150W Hazardous Location LED Luminaire - Class I Div 2 - 140 LM/W - CCT 5000K | EX-150W A3D50D120

Ledsion 150W Hazardous Location LED Luminaire – UL 844 certified for Class I Div 2, Class II & III. 140 LM/W, 0-10V dimming, IP66/IK10 rated. Ideal for petrochemical, offshore, wastewater, and heavy industrial hazardous areas.

Features

• Hazardous Location Certified – UL 844 certified for Class I Division 2, Class II Division 1/2, and Class III
• High Performance – Up to 140 LM/W efficiency with 2100+ lumens output
• 0-10V Dimming – Smooth and reliable dimming capability
• Robust Construction – Die-cast aluminum housing with tempered glass lens, IK08/IK10 impact resistance
• Marine Rated – UL 1598A Marine Outside Type approved
• Battery Backup Option – Emergency lighting version available (UL 924)
• Wide Operating Temperature – -40°F to 131°F (-40°C to 55°C)
• Long Lifespan – L70 > 150,000 hours @ 55°C
• Multiple Mounting Options – Ceiling mount and wall mount with brackets

Specifications

ParameterDetailsModelEX-150W A3D50D120Wattage150WLight Efficiency140 LM/WLumen Output2100+ LMColor Temperature5000K (Daylight)Beam Angle120°Voltage120-277V ACPower Factor0.95Dimming0-10V DimmingCRI>72Protection RatingIP66 / IK10Housing MaterialDie-cast Aluminum + Tempered GlassCertificationsUL 844, UL 1598, UL 1598A, UL 924Warranty5 Years

Applications The Ledsion EX Series 150W Hazardous Location LED Luminaire is engineered for extreme and high-risk environments, including:

• Power Plants & Petrochemical Facilities
• Chemical Processing Plants
• Wastewater Treatment Plants
• Offshore Platforms & Marine Environments
• Heavy Industrial Storage & Loading Docks
• Coal Mines, Paper Mills & Metallurgical Industry
• Food & Alcohol Processing Facilities

Ideal for areas with moisture, dust, corrosion, vibration, and explosive atmospheres.
